Clutch release bearing Nissan Patrol Y60 Y61

Clutch release bearing for Nissan Patrol Y60 and Y61, designed for compatible clutch release systems with 2.8 TD and 3.0 Di / CRD engines. Also used in Patrol Shop Heavy-Duty clutch kits, in the Y61-type bearing configuration.

Features

• Transfers clutch release mechanism force to the pressure plate diaphragm
• Y61-type release bearing configuration, also suitable for certain Nissan Patrol Y60 clutch assemblies
• Used in Patrol Shop 250 mm and 275 mm Heavy-Duty clutch kits
• Can replace the smaller release bearing fitted to certain Y60 versions when used with the appropriate bearing carrier

Specifications

• Type: Clutch release bearing
• Inner diameter: 40 mm
• Outer diameter: 81 mm
• Height: 19 mm

Compatibility

• Nissan Patrol Y60 2.8 TD - RD28T, compatible configurations
• Nissan Patrol Y61 2.8 TD - RD28Ti
• Nissan Patrol Y61 3.0 Di / CRD - ZD30

Installation

• Check compatibility with the existing bearing carrier, clutch fork and pressure plate.
• Replace the bearing if excessive play, operating noise or wear is present.
• During installation, apply suitable lubricant only to the specified clutch release mechanism contact points, following the applicable installation instructions.

Compatible Accessories

• OE Nissan clutch release-bearing carrier Patrol Y60/Y61 2.8 - required for certain Y60 configurations
• OE Nissan bearing carrier retaining spring Patrol Y60/Y61 2.8 - secures the bearing to the appropriate carrier
